Powered By

Forklift Handling
The Range/DIESEL/Endurolift EL-F100D
PHOTO TBD
DIESEL

Endurolift EL-F100D

MODEL EL-F100D

BEST FOR:OutdoorHeavy Lifting

Compact, powerful 10-ton diesel forklift built for reliable everyday performance.

CAPACITY
10.0T
LIFT HEIGHT
3.0m
POWER
Diesel

Backed by Forklift Handling, recognised on the Financial Times Africa's Fastest Growing Companies list.

ENQUIRE ABOUT THIS MODEL
Interested in the Endurolift EL-F100D?ENQUIRE ABOUT Endurolift EL-F100D
OVERVIEW

Ten-ton diesel for substantial industrial loads

The Endurolift EL-F100D FORZA is a powerful 10-ton diesel forklift configured with a 4,000 mm lift height for outdoor and heavy-lifting applications. Its Isuzu 6BG1 engine produces 82 kW at 2,000 rpm, with the 10,000 kg capacity rated at a 600 mm load centre. The truck records travel speeds of 30 km/h loaded and 32 km/h unloaded, a 3,940 mm outside turning radius and 21% maximum gradeability at full load. A 12,800 kg total truck weight and hydraulic transmission support dependable handling of substantial industrial loads.

KEY FEATURES
10,000 kg rated capacity at a 600 mm load centre
4,000 mm approved configured lift height
Isuzu 6BG1 diesel engine
82 kW rated output at 2,000 rpm
30 km/h loaded and 32 km/h unloaded travel speed
21% maximum gradeability at full load
3,940 mm outside turning radius
12,800 kg total truck weight with hydraulic transmission
SPECIFICATIONS

FULL TECHNICAL DATA

Model
El-F100D
Power Type
Diesel
Rated Load Capacity
Q(kg)
10000
Rated Lift Height
H3(mm)
3000
ISUZU Engine
kW
82
Lifting Speed
mm/sec
330
Maximum Gradeability
%
21
Minimum Aisle Width
Ast(mm)
5842
Turning Radius
Wa(mm)
3940
ENQUIRE

GET A QUOTE ON THE Endurolift EL-F100D

No prices online. Tell us your application and we'll respond with a tailored quote.

Serviced by Forklift Handling, Johannesburg. Response within an hour.

WhatsApp, call, or email us: choose what works best for you.

Enquiring about: Endurolift EL-F100D
